MODEL 680-P2 PORTABLE SCALES

STANDARD FEATURES
• Carbon steel construction with powder coat finish.
• Two 12″, folding, easy incline, side loading ramps.
• (4) Internally mounted, IP 67 water resistant rated load cells.
• Column mounted polycarbonate NEMA 4X junction box for convenient corner adjustments.
• Structural tubular construction.
• Diamond tread deck plate with eye bolt holes.
• 150% Overload protection
• 100% End loading capacity.
• Shielded load cell cables and 10 foot indicator cable.
• Ultra-lo profile (1.5″ above the floor).
• 1 part in 5000 accuracy.
• (2) poly bonded 4″ straight wheel casters with roller bearings and grease fittings (front).
• (2) poly bonded 4″ swivel wheel casters with roller bearings and grease fittings (rear).
• Wheel jacks to lift and lower scale.
• 40″ high indicator column with mounting plate.
• OSHA orange safety handle grips.

MODEL 680-P2 OPTIONS
• Smooth deck plate with eye bolt holes.
• Locking rear swivel wheel.
• Indicator mounting plate with 180° swivel.
• Stainless steel load cells.
• Hermetically sealed stainless steel load cells.
• “FM” approved load cells.
• “FM” approved stainless steel Nema 4X junction box
